2480.15.07500. Gas spring Standard
Max. stroke HUBMAX = 25 mm, Hub Hub = 26, Order No BC = 2480.15.07500.025, Design ASF = with valve, Spring force start FA = 7540 daN
Log in to view price, availability, and order the product.
Products
Showing 1-10 of 38 items
| SKU | Design | Spring force start | Max. stroke | |
|---|---|---|---|---|
| 2480.15.07500.025 | with valve | 7540 daN | 25 mm | |
| 2480.15.07500.025.P | without valve | 7540 daN | 25 mm | |
| 2480.15.07500.038 | with valve | 7540 daN | 38 mm | |
| 2480.15.07500.038.P | without valve | 7540 daN | 38 mm | |
| 2480.15.07500.050 | with valve | 7540 daN | 50 mm | |
| 2480.15.07500.050.P | without valve | 7540 daN | 50 mm | |
| 2480.15.07500.063 | with valve | 7540 daN | 63.5 mm | |
| 2480.15.07500.063.P | without valve | 7540 daN | 63.5 mm | |
| 2480.15.07500.075 | with valve | 7540 daN | 75 mm | |
| 2480.15.07500.075.P | without valve | 7540 daN | 75 mm | |
| 2480.15.07500.080 | with valve | 7540 daN | 80 mm | |
| 2480.15.07500.080.P | without valve | 7540 daN | 80 mm | |
| 2480.15.07500.088 | with valve | 7540 daN | 87.5 mm | |
| 2480.15.07500.088.P | without valve | 7540 daN | 87.5 mm | |
| 2480.15.07500.100 | with valve | 7540 daN | 100 mm | |
| 2480.15.07500.100.P | without valve | 7540 daN | 100 mm | |
| 2480.15.07500.113 | with valve | 7540 daN | 113 mm | |
| 2480.15.07500.113.P | without valve | 7540 daN | 113 mm | |
| 2480.15.07500.125 | with valve | 7540 daN | 125 mm | |
| 2480.15.07500.125.P | without valve | 7540 daN | 125 mm | |
| 2480.15.07500.138 | with valve | 7540 daN | 138 mm | |
| 2480.15.07500.138.P | without valve | 7540 daN | 138 mm | |
| 2480.15.07500.150 | with valve | 7540 daN | 150 mm | |
| 2480.15.07500.150.P | without valve | 7540 daN | 150 mm | |
| 2480.15.07500.160 | with valve | 7540 daN | 160 mm | |
| 2480.15.07500.160.P | without valve | 7540 daN | 160 mm | |
| 2480.15.07500.175 | with valve | 7540 daN | 175 mm | |
| 2480.15.07500.175.P | without valve | 7540 daN | 175 mm | |
| 2480.15.07500.200 | with valve | 7540 daN | 200 mm | |
| 2480.15.07500.200.P | without valve | 7540 daN | 200 mm | |
| 2480.15.07500.225 | with valve | 7540 daN | 225 mm | |
| 2480.15.07500.225.P | without valve | 7540 daN | 225 mm | |
| 2480.15.07500.250 | with valve | 7540 daN | 250 mm | |
| 2480.15.07500.250.P | without valve | 7540 daN | 250 mm | |
| 2480.15.07500.275 | with valve | 7540 daN | 275 mm | |
| 2480.15.07500.275.P | without valve | 7540 daN | 275 mm | |
| 2480.15.07500.300 | with valve | 7540 daN | 300 mm | |
| 2480.15.07500.300.P | without valve | 7540 daN | 300 mm |
