2487.15.01000. Gas spring POWERLINE
Hub Hub = 11, Order No BC = 2487.15.01000.010, Design ASF = with valve, Spring force start FA = 920 daN, Max. stroke HUBMAX = 10 mm
Log in to view price, availability, and order the product.
Products
Showing 1-10 of 26 items
| SKU | Design | Spring force start | Max. stroke | |
|---|---|---|---|---|
| 2487.15.01000.013 | with valve | 920 daN | 13 mm | |
| 2487.15.01000.013.P | without valve | 920 daN | 13 mm | |
| 2487.15.01000.016 | with valve | 920 daN | 16 mm | |
| 2487.15.01000.016.P | without valve | 920 daN | 16 mm | |
| 2487.15.01000.019 | with valve | 920 daN | 19 mm | |
| 2487.15.01000.019.P | without valve | 920 daN | 19 mm | |
| 2487.15.01000.025 | with valve | 920 daN | 25 mm | |
| 2487.15.01000.025.P | without valve | 920 daN | 25 mm | |
| 2487.15.01000.032 | with valve | 920 daN | 32 mm | |
| 2487.15.01000.032.P | without valve | 920 daN | 32 mm | |
| 2487.15.01000.038 | with valve | 920 daN | 38 mm | |
| 2487.15.01000.038.P | without valve | 920 daN | 38 mm | |
| 2487.15.01000.050 | with valve | 920 daN | 50 mm | |
| 2487.15.01000.050.P | without valve | 920 daN | 50 mm | |
| 2487.15.01000.063 | with valve | 920 daN | 63 mm | |
| 2487.15.01000.063.P | without valve | 920 daN | 63 mm | |
| 2487.15.01000.075 | with valve | 920 daN | 75 mm | |
| 2487.15.01000.075.P | without valve | 920 daN | 75 mm | |
| 2487.15.01000.080 | with valve | 920 daN | 80 mm | |
| 2487.15.01000.080.P | without valve | 920 daN | 80 mm | |
| 2487.15.01000.100 | with valve | 920 daN | 100 mm | |
| 2487.15.01000.100.P | without valve | 920 daN | 100 mm | |
| 2487.15.01000.125 | with valve | 920 daN | 125 mm | |
| 2487.15.01000.125.P | without valve | 920 daN | 125 mm | |
| 2487.15.01000.010 | with valve | 920 daN | 10 mm | |
| 2487.15.01000.010.P | without valve | 920 daN | 10 mm |
