2482.72. Gas spring small dimension and low force

2482.72. Gas spring small dimension and low force

New generation available – see product alternatives
Description:
The gas springs are colour-coded according to the spring force rating ranges 13-25-38-50 daN.

All springs, regardless of their spring force ratings, are of the same design. The differing forc
SKU: 2482-72-
Order No
Spring force start
Length
Piston rod diameter
6 mm Reset
Cylinder pipe diameter
12 mm Reset
Log in to view price, availability, and order the product.

Products

Showing 1-10 of 65 items
SKU Spring force start Length Piston rod diameter Cylinder pipe diameter
2482.72.00000.007 0 56 mm 6 mm 12 mm
2482.72.00000.010 0 62 mm 6 mm 12 mm
2482.72.00000.013 0 67.4 mm 6 mm 12 mm
2482.72.00000.015 0 72 mm 6 mm 12 mm
2482.72.00000.019 0 80 mm 6 mm 12 mm
2482.72.00000.025 0 92 mm 6 mm 12 mm
2482.72.00000.038 0 118 mm 6 mm 12 mm
2482.72.00000.050 0 142 mm 6 mm 12 mm
2482.72.00000.063 0 172 mm 6 mm 12 mm
2482.72.00000.075 0 195 mm 6 mm 12 mm
2482.72.00000.080 0 205 mm 6 mm 12 mm
2482.72.00000.100 0 245 mm 6 mm 12 mm
2482.72.00000.125 0 295 mm 6 mm 12 mm
2482.72.00013.007 13 56 mm 6 mm 12 mm
2482.72.00013.010 13 62 mm 6 mm 12 mm
2482.72.00013.013 13 67.4 mm 6 mm 12 mm
2482.72.00013.015 13 72 mm 6 mm 12 mm
2482.72.00013.019 13 80 mm 6 mm 12 mm
2482.72.00013.025 13 92 mm 6 mm 12 mm
2482.72.00013.038 13 118 mm 6 mm 12 mm
2482.72.00013.050 13 142 mm 6 mm 12 mm
2482.72.00013.063 13 172 mm 6 mm 12 mm
2482.72.00013.075 13 195 mm 6 mm 12 mm
2482.72.00013.080 13 205 mm 6 mm 12 mm
2482.72.00013.100 13 245 mm 6 mm 12 mm
2482.72.00013.125 13 295 mm 6 mm 12 mm
2482.72.00025.007 25 56 mm 6 mm 12 mm
2482.72.00025.010 25 62 mm 6 mm 12 mm
2482.72.00025.013 25 67.4 mm 6 mm 12 mm
2482.72.00025.015 25 72 mm 6 mm 12 mm
2482.72.00025.019 25 80 mm 6 mm 12 mm
2482.72.00025.025 25 92 mm 6 mm 12 mm
2482.72.00025.038 25 118 mm 6 mm 12 mm
2482.72.00025.050 25 142 mm 6 mm 12 mm
2482.72.00025.063 25 172 mm 6 mm 12 mm
2482.72.00025.075 25 195 mm 6 mm 12 mm
2482.72.00025.080 25 205 mm 6 mm 12 mm
2482.72.00025.100 25 245 mm 6 mm 12 mm
2482.72.00025.125 25 295 mm 6 mm 12 mm
2482.72.00038.007 38 56 mm 6 mm 12 mm
2482.72.00038.010 38 62 mm 6 mm 12 mm
2482.72.00038.013 38 67.4 mm 6 mm 12 mm
2482.72.00038.015 38 72 mm 6 mm 12 mm
2482.72.00038.019 38 80 mm 6 mm 12 mm
2482.72.00038.025 38 92 mm 6 mm 12 mm
2482.72.00038.038 38 118 mm 6 mm 12 mm
2482.72.00038.050 38 142 mm 6 mm 12 mm
2482.72.00038.063 38 172 mm 6 mm 12 mm
2482.72.00038.075 38 195 mm 6 mm 12 mm
2482.72.00038.080 38 205 mm 6 mm 12 mm
2482.72.00038.100 38 245 mm 6 mm 12 mm
2482.72.00038.125 38 295 mm 6 mm 12 mm
2482.72.00050.007 50 56 mm 6 mm 12 mm
2482.72.00050.010 50 62 mm 6 mm 12 mm
2482.72.00050.013 50 67.4 mm 6 mm 12 mm
2482.72.00050.015 50 72 mm 6 mm 12 mm
2482.72.00050.019 50 80 mm 6 mm 12 mm
2482.72.00050.025 50 92 mm 6 mm 12 mm
2482.72.00050.038 50 118 mm 6 mm 12 mm
2482.72.00050.050 50 142 mm 6 mm 12 mm
2482.72.00050.063 50 172 mm 6 mm 12 mm
2482.72.00050.075 50 195 mm 6 mm 12 mm
2482.72.00050.080 50 205 mm 6 mm 12 mm
2482.72.00050.100 50 245 mm 6 mm 12 mm
2482.72.00050.125 50 295 mm 6 mm 12 mm
